M10
The M10 hydraulic starter motor is the smallest model in the range.
Suitable for engines with up to 4 litres in capacity, it can produce a maximum torque of 30Nm at 3,000 psi (207 bar). The M10 is made from cast iron (including the flange and pinion housing), making it highly resistant to rust and corrosion.
SOLUTION DETAILS
The M10 is fitted with a heavy-duty inertia bendix and pinion. These are machined from one cast block, eliminating the process of pressing the pinion onto the bendix cup which is a common failure point found in many other starter motors across various applications
Non-spark pinions
Depending on your application, the M10 hydraulic starter motor can be fitted with either a steel or beryllium copper pinion. If the environment is potentially hazardous, a beryllium copper pinion helps to reduce the risk of sparks.
Key Advantages
- Interchangeable design: Both the pinion and mounting flange are interchangeable. This allows the configuration of the starter motor to be altered to suit any application.
- Guaranteed start: Hydraulic energy can be stored indefinitely providing the system is installed and maintained to Powerstart specifications. Even after discharge, it can be quickly and easily recharged using a hand pump.
- Performance in all conditions: Hydraulic starters are unaffected by either very hot or cold conditions, provided the correct viscosity of oil is used. They similarly operate efficiently following extensive periods of shut down.
- Low maintenance: Hydraulic starting systems are designed to last as long as your engine so why not enjoy low maintenance and replacement costs, as well as peace of mind? All internal components are immersed in oil, protecting it from the adverse environmental conditions that damage electric or vane starters.
Optional Features and Configurations
Technical Specs
Performance
Max Torque
Max Working Pressure
Design Pressure
Viscosity Range
Speed Range
Duty Cycle
Volumetric Efficiency
Temperature Range
Physical
Displacement
Length
Diameter
Mass
Construction
Fluid media
Rotation
Inlet port
Outlet port
Power Curves
Compare Solutions
Model
Max Engine Size
Max Torque
M10
1-4 litres
30 Nm
M16
1-5 litres
40 Nm
M22
3-8 litres
66 Nm
M28
4-12 litres
84 Nm
M33
TBC
TBC
M38
TBC
124 Nm
M66
TBC
216 Nm
